How to set parameters by scanning barcode

Switch On Off Setting Codes

Note:If need set the scanner with different functions,please scan "Switch On Setting Codes".
The default setting "Switch Off Setting Codes"means the scanner can read all setting
barcodes on this Quick Guide,but invalid.

How to Use(Note: please pair in corresponding Bluetooth Mode)
Connect the Bluetooth dongle with a PC (not with a laptop built-in Bluetooth or Bluetooth adapter) Plug Bluetooth dongle to PC USB,(the scanner has paired with Bluetooth dongle well before delivery), and press the button,it can work directly.
Note: if cannot upload data via Bluetooth dongle,please first scan "Factory Bluetooth Mode" then scan "Match Enforced".After scanning the following two setting barcodes,green indicator light flushes and in pairing status. When pairing done, the blue indicator light on always.

Connect it with your PC's built-in Bluetooth or Bluetooth adapter (not with a Bluetooth dongle)-Windows 7
(Note:similar pairing steps in other Windows systems,please contact our customer service for detailed user manual.)
1.Plug in the Bluetooth adapter then the Bluetooth icon will show.
2.Double click the Bluetooth icon and then the "Devices and Printers"will show.
3.First scan "Bluetooth HID Mode"then scan "Match"barcode or press the trigger button for 10 seconds,blue and green indicator light flashes and the Bluetooth scanner enters to pairing status.
4.Click "add a device"and there comes a dialog box that shows "Barcode Scanner HID".
5.Right click the device icon and right click again to select the properties.
6.Select "Drivers for keyboard,mice,etc HID"in the properties dialog box and click yes.
7.After installation there will be a balloon to show installation success.The device manager has a new HID keyboard device.
8.Now the Bluetooth installation finished.Open any edit box like notepad to start reading and uploading bar codes.
